Brand: Cummins Type: 4 Cylinder In Line
Displacement: 3.9L Dry Weight: 338kg
Bore X Stroke: 102mm X 120mm Dimension: 778*634*912
Rated Output: 77kw/105hp Rated Speed: 2800RPM
High Light: 4bt3.9 diesel engine set 2800RPM
105hp 2800RPM 4 cylinder generator
105hp cummins engine generator
Genuine Cummins 4 Cylinder 4bt3.9 Diesel Engine Assembly DCEC High Performance Machinery Engine
High Fuel Efficiency: 20% fewer oil consumption than other competitive products.
Compacted Yet Durable And Dependable Engine:6B series engine contains up to 40% fewer parts than competition engines in its class. This results in a better power-to-weight ration,a less chance of faliure and lower repair cost.
Advanced design and manufacturing:Make the engine delivers superior performance and lower cost than competitive engines.
Excellent cold start performance:with improved 6.6kw starter and intake air heater.
General data of Cummins 4BT3.9-C105 Construction Machinery Engine
Engine Model Cummins 4BT3.9-C105
Type 4 cylinder in line
Displacement 3.9L
Bore&Stroke 102*120mm
Dry Weight 338kg
Dimension(L*W*H) 778*634*912
Performance Data of Cummins 4BT3.9-C105 Construction Machinery Engine
Rated Output 77kw/105hp
Rated Speed 2800RPM
Max Torque/Speed 330N.m/1500RMP
Torque/Rated Speed 263N.m/2800RMP
Minimum Fuel Consumption/Speed 227g/kw.h/1500RMP
Maximum Fuel Consumption/Speed 270g/kw.h/2800RMP
Fuel Consumption/rated speed 270g/kw.h/2800RMP
Technical data of Cummins 4BT3.9-C105 Construction Machinery Engine
Aspiration Turbocharged
Fuel System PW Pump/RSV Governor 15%
Coolant capacity-engine only 7.9 litre
Minimum Idle speed 750RPM
Maximum Speed(10% rated load) 3200RPM
Compression ratio 16:5:1
The above is general technical information of Cummins 4BT3.9-C105 industrial appliion engine.It is also for us to supply the Cummins 4BT3.9-C105 genuine parts and 4BT3.9-C105 engine power pack.
